library IEEE; use IEEE.std_logic_1164.all; entity bejoy_fa is port(In1,In2,c_in : in std_logic; sum, c_out : out std_logic); end bejoy_fa; architecture arc of bejoy_fa is component half_adder port(a,b : in std_logic; sum, carry : out std_logic); end component; component or_2 port(a,b : in std_logic; c : out std_logic); end component; signal s1, s2, s3 : std_logic; begin H1: half_adder port map(a=>In1, b=>In2, sum=>s1, carry=>s3); H2: half_adder port map(a=>s1, b=>c_in, sum=>sum, carry=>s2); O1: or_2 port map(a=> s2, b=>s3, c=>c_out); end arc; entity half_adder is port (a,b : in bit ; sum,carry : out bit); end half_adder; architecture arc of half_adder is begin sum<= a xor b; carry <= a and b; end arc; entity or_2 is port (a,b : in bit ; c : out bit); end or_2; architecture arc of or_2 is begin c<= a or b; end arc;
